Product Details:
|
Type: | Gluing Machine | Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company, Carton Pack, Corrugated Pack, Corrugated Box, Packaging |
---|---|---|---|
Showroom Location: | Egypt, Turkey, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, | Video Outgoing-inspection: | Provided |
Machinery Test Report: | Provided | Warranty Of Core Components: | 1 Year |
Core Components: | PLC, Engine | Condition: | New |
Application: | Corrugated Carton Box | Packaging Type: | Cartons |
Packaging Material: | Plastic | Automatic Grade: | Automatic |
Driven Type: | Electric | Voltage: | 380V |
Weight: | 8000 KG | Warranty: | 1 Year |
Key Selling Points: | High-accuracy | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
Name: | Folder&gluer | Speed: | 60-150 Sheets/min |
Function: | Paper Cardboard Box Gluing Machine | Color: | Customer Required HOT MELT Machine |
Feeding Way: | Automatic Feeding | Marketing Type: | Hot Product 2023 |
Port: | Tianjin Port |
Type | LC-2600 |
Max.Dimension (a + b) X2 (mm) | 2600mm |
Min.Dimension (a + b) X2 (mm) | 720mm |
Max.Dimension (C + D + C) X2 (mm) | 1000mm |
Min.Dimension (C + D + C) X2 (mm) | 300mm |
Max. Width B (mm) | 550mm |
Min. Width B (mm) | 160mm |
Max. Length A (mm) | 750mm |
Total Power (Kw) | 23kw |
Min. Length A (mm) | 160mm |
Nail Tongue Width E (mm) | 35-40mm |
Machine Speed(Nail/Min) | 800nails/min |
Number of nails | 1-99 |
Nail distance (mm) | 30-80mm |
Nail box speed | 60m/min |
110-130m/min | 60m/min |
