Product Details:
|
Warranty: | 1 Year, 1 Year | Type: | Other |
---|---|---|---|
Applicable Industries: | Carton Box Making | Showroom Location: | Egypt, India, Mexico, Russia |
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Warranty Of Core Components: | 1 Year | Core Components: | Motor, Gear |
Condition: | New | Application: | Carton |
Packaging Type: | Cartons, Pouch | Packaging Material: | Plastic |
Automatic Grade: | Semi-automatic | Driven Type: | Electric |
Voltage: | 380V | Power: | 7.5kw |
Weight: | 5000 KG | Dimension(L*W*H): | Machine Model |
Key Selling Points: | Easy To Operate | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
Usage: | Making Carton | Packing Material: | Plastic Film |
Packing Speed: | 20-23PIECES/min | Keyword: | DIE-CUTTING MACHINE |
Material: | Cast Iron | Port: | TIANJIN |
Model | Inner chase size (mm) | Speed (strokes/min) | Max. rule length (m) | Motor power(kw) | Machine’s weight(kg) | Overall dimensions (mm) |
ML-1800 | 1800×1280 | 16±2 | <50 | 11 | 14500 | 2180×2760×2100 |
ML-1700 | 1700×1400 | 16±2 | <45 | 11 | 13500 | 2170×2660×2100 |
ML-1600 | 1600×1325 | 13±2 | <50 | 11 | 12500 | 2760×2300×2300 |
ML-1500 | 1500×1050 | 14±2 | <45 | 7.5 | 7000 | 2440×2000×1980 |
ML-1400 | 1400×1000 | 15±2 | <45 | 7.5 | 6800 | 2000×2340×2000 |
ML-1300 | 1300×920 | 15±2 | <40 | 5.5 | 6000 | 2000×2240×2000 |
ML-1200 | 1200×830 | 20±2 | <32 | 4 | 4800 | 1950×2100×1950 |
ML-1100 | 1100×790 | 20±2 | <32 | 4 | 4500 | 1950×2100×1950 |
ML-1040 | 1040×720 | 20±3 | <30 | 4 | 4800 | 1700×2150×1760 |
ML-930 | 930×670 | 20±3 | <25 | 4 | 3500 | 1570×1800×1760 |
ML-750 | 750×520 | 25 | <15 | 2.2 | 2100 | 1360×1550×1520 |
ML-720 | 720×510 | 25 | <15 | 2.2 | 2000 | 1360×1500×1520 |
