Product Details:
|
Type: | Inkjet Printer | Print Dimension: | 2500mm |
---|---|---|---|
Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Food Shop, Printing Shops, Construction Works , Food & Beverage Shops, Advertising Company, Paper Printer, Card Printer, Digital Printing Machine Corrugated Box Inkjet Pri | Condition: | New |
Plate Type: | No Plate | Usage: | Paper Printer, Card Printer, Corrugated Board Printer |
Automatic Grade: | Automatic | Color & Page: | Multicolor |
Voltage: | 220V 380V 440V | Dimensions(L*W*H): | 4200*1500*2500mm |
Weight: | 5000 KG | Warranty: | 1 Year |
Ink Type: | Fast Dry Ink | Key Selling Points: | No Need Printing Plate |
Marketing Type: | New Product 2022 | Machinery Test Report: | Provided |
Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
Core Components: | Motor, Pressure Vessel, Pump, PLC, Gear, Bearing, Gearbox, Engine | Print Speed: | 12Pcs/min |
Name: | SINGLE PASS DIGITAL PRINTER Machine | Printing Material: | Corrugated Board |
Ink Color: | Y (yellow) M (red) C (blue) K (black) | Ink Supply Mode: | Automatic Continuous Ink Supply |
Printhead Height: | 0mm-20mm | Print Material Thickness: | 2mm-20mm(Customizable) |
Printing Accuracy: | 600dpi | Printing Efficiency: | 60-120m/ Min |
Port: | Tianjin Port |
Nozzle module | Original Epson i3200a1 industrial nozzle |
Ink type | CMYK environmentally friendly water based ink |
Ink color | Y (yellow) m (red) C (blue) K (black) |
Ink supply mode | Automatic continuous ink supply |
Printhead Height | 0mm-20mm |
Print material thickness | 2mm-20mm(Customizable) |
Printing accuracy | 600dpi |
Printing efficiency | 60-120m/ min |
Printing format | ≤7500mm*Unlimited length |
Drying rate | The drying speed of other materials varies with the water absorption of the materials |
Power | Fan fully open power consumption 13kw |
Electricity consumption | Three phase ground wire AC380 ± 5%,50Hz |
Operating system | Rip software, printing software, Windows 7, windows 10 64 bit operating system |
Work environment | Room temperature 15 ℃ - 35 ℃, humidity 30% - 70% |
